Home Products

Nylon Cable Drag Chain

Energy Chain Cable Carrier 75mm 100mm 150mm Width For Sugar Mill Industry

Brand Name:	BNEE
Model Number:	ZQ ZF
MOQ:	1
Price:	10$-60$
Payment Terms:	T/T
Supply Ability:	200 metres per day

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE IS09001

Material:

Steel Nylon

Inner Height:

07mm-80mm

Inner Width:

07mm-300mm

Outer Height:

10mm-119mm

Outer Width:

10mm-364mm

Bending Radius:

18mm-300mm

Packaging Details:

cardboard box

Highlight:

150mm Width Energy Chain Cable Carrier

Sugar Mill Industry Chain Cable Carrier

100mm Width Chain Cable Carrier

Product Description

Energy Chain Cable Carrier 75mm 100mm 150mm Width For Sugar Mill Industry

Product Specifications

Attribute	Value
Material	Steel & Nylon
Inner Height	07mm-80mm
Inner Width	07mm-300mm
Outer Height	10mm-119mm
Outer Width	10mm-364mm
Bending Radius	18mm-300mm

Cable Drag Chain Overview

Our cable drag chains are engineered for optimal cable protection and organization in demanding industrial environments like sugar mills. Available in various materials and designs to suit specific application requirements.

Classification by Material

Steel Drag Chains: High load-bearing capacity for heavy-duty industrial applications
Plastic Drag Chains: Lightweight with excellent corrosion resistance
Fiberglass Reinforced Plastic (FRP): Combines strength with flexibility

Design Variations

Open-Type: Provides ventilation and easy installation
Closed-Type: Maximum protection against dust and contaminants

Key Benefits

Extends cable service life by preventing abrasion and impact damage
Prevents cable tangling and reduces workplace hazards
Reduces operational noise in sensitive environments
Simplifies maintenance and inspection processes

Industrial Applications

Our cable carriers are ideal for:

Automotive manufacturing and assembly lines
CNC machines and industrial robotics
Material handling and conveyor systems
Medical equipment and diagnostic machines
Aerospace and defense applications
Sugar mill machinery and processing equipment

Technical Specifications

Type	Bending Radius (mm)	Inner Height (mm)	Inner Width (mm)	Outer Height (mm)	Outer Width (mm)
ZQ3250	63-300	32	51	54	72
ZQ3262	63-300	32	62	54	90
ZQ3275	63-300	32	75	54	97
ZQ3287	63-300	32	87	54	109
ZQ32100	63-300	32	100	54	122
ZQ32112	63-300	32	112	54	134
ZQ32125	63-300	32	125	54	147
ZQ32137	63-300	32	137	54	159
ZQ32150	63-300	32	150	54	172
ZQ32162	63-300	32	162	54	184
ZQ32175	63-300	32	175	54	197
ZQ32187	63-300	32	187	54	197
ZQ32200	63-300	32	200	54	222
ZQ32225	63-300	32	225	54	247
ZQ32250	63-300	32	250	54	272
